📊 Product Specifications Overview
| Item | Specification |
|---|---|
| Model | INTOP 05 Control Valve |
| Flow Rate | 3.5m³/h (15.4 gpm) |
| Connection Type | 1/2", 3/4", 1", NPT & BSP |
| Valve Body Material | PPO |
| Operating Pressure | 20 – 125 psi |
| Operating Temperature | 1°C – 55°C |
| Tank Diameter Compatibility | 6" – 16" |
| Power Input | 110–120V / 220–240V, 50/60Hz |
| Output Power | 15VDC, 1A |
| Weight (Net/Gross) | 1.8 kg / 2.0 kg |
| Dimensions (Valve Body) | 238×197×172 mm |
| Package Dimensions | 268×230×260 mm |
⚙️ Technical Highlights
-
High-Precision Flow Meter – Accuracy ±5%, range 0.25–30 gpm
-
Removable Operation Panel – Easy maintenance and upgrades
-
Built-in Bypass Valve – No system downtime during maintenance
-
9 Programmable Cycles – Customizable regeneration process (backwash, slow rinse, fast rinse, brine refill, etc.)
-
Multi-language Operation – English interface, clear and easy to use
📦 Packaging & Accessories
-
Standard Valve Body ×1
-
Removable Operation Panel ×1
-
Mounting Bracket ×1
-
Wiring Terminals & Power Adapter (optional)
-
User Manual & Warranty Card
Packing: Corrugated Box
Selling Unit: Single Unit
Gross Weight: 2.0 kg
🏭 Applicable Scenarios
-
Commercial Water Softening Systems (hotels, schools, factories)
-
Whole-House Residential Water Softening
-
Garage Workshops, Outdoor Camps
-
Water Filtration System Control
✅ Quality Assurance
-
1-Year Warranty – Valve body and electronic components
-
Proprietary Mold Development – Precise structure, leak-proof and reliable
-
Factory Technical Support – Installation guidance and troubleshooting
-
Programmable Chip – Supports future functional upgrades
🛠️ Installation Instructions
-
Compatible with standard 6"–16" tanks
-
Standard 1" NPT drain port, 3/8" quick-connect brine line
-
Flexible installation height from tank top
🔄 Upgrade Options
-
Standard Version: Basic control functions, stable and reliable
-
Bluetooth Version (Optional): Supports mobile APP remote control, data logging, multi-language settings
